DIN Loose Flange (Lap Joint Flanges)
DIN 2673 Loose Flange And Ring With Neck For Welding PN10
Standard: DIN 2673
Flange type: Loose Flange And Ring With Neck For Welding
Size range: DN10-DN1200
Pressure: PN10
Material: Stainless steel , Alloy Steel , Carbon Steel
Standard: DIN 2673
Flange type: Loose Flange And Ring With Neck For Welding , lap joint flange
Size range: DN10-DN1200
Pressure class: PN10
Connection type: Ring type joint, lap-joint face,Raised face, flat face, male-female,Large tongue & groove,small tongue & groove.
Process: Forged or Stamped
Specialize: As per drawing
Material:
Stainless Steel Material:
ASTM A182 F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L
Duplex stainless steel UNS S32304,S31803,S32205.
Super Duplex stainless steel UNS S32750/S32760/S31260/S32550/S32707
Carbon Steel Material:
ASTM A105, Q235, A350 LF2,ASTM A694 F42/F46/F52/F60/F65/F70/F80
Alloy Steel Material:
ASTM A 182, GR F1,F5, F9, F11, F22, F91
Copper&Nickel Alloy Material:
CU/NI 90/10, CU/NI 70/30
Nickel Alloy Material:
Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276
Surface treatment: Anti-rust oil, transparent/yellow/black,Anti-rust paint, Zinc,Hot dipped galvanized
Usage: Oil field, Offshore, Water system, Shipbuilding, Natural gas,Electric power, Pipe projects,etc
Standard: DIN 2673
Flange type: Loose Flange And Ring With Neck For Welding
Size range: DN10-DN1200
Process: Forged or Stamped
|
Normal |
O.D. |
Thk |
Length |
Diam of |
Hub |
Raised |
Diam, of |
No. of |
Diam, of |
Diam, of |
Fillet |
|
inch |
O |
C |
Y |
X |
A |
R |
BD |
BN |
BH |
DB |
r1 |
|
26" |
785.9 |
41.1 |
88.9 |
684.3 |
661.9 |
711.2 |
744.5 |
36 |
22.4 |
3/4" |
9.7 |
|
28" |
836.7 |
44.5 |
95.3 |
735.1 |
712.7 |
762 |
795.3 |
40 |
22.4 |
3/4" |
9.7 |
|
30" |
887.5 |
44.5 |
100.1 |
787.4 |
763.5 |
812.8 |
846.1 |
44 |
22.4 |
3/4" |
9.7 |
|
32" |
941.3 |
46 |
108 |
839.7 |
814.3 |
863.6 |
900.2 |
48 |
22.4 |
3/4" |
9.7 |
|
34" |
1004.8 |
49.3 |
110.2 |
892 |
865.1 |
920.8 |
957.3 |
40 |
25.4 |
7/8" |
9.7 |
|
36" |
1057.1 |
52.3 |
117.3 |
944.6 |
915.9 |
971.6 |
1009.7 |
44 |
25.4 |
7/8" |
9.7 |
|
38" |
1124 |
53.8 |
124 |
997 |
968.2 |
1022.4 |
1069.8 |
40 |
28.4 |
1" |
9.7 |
|
40" |
1174.8 |
55.6 |
128.5 |
1049.3 |
1019 |
1079.5 |
1120.6 |
44 |
28.4 |
1" |
9.7 |
|
42" |
1225.6 |
58.7 |
133.4 |
1101.9 |
1069.8 |
1130.3 |
1171.4 |
48 |
28.4 |
1" |
11.2 |
|
44" |
1276.4 |
60.5 |
136.7 |
1152.7 |
1120.6 |
1181.1 |
1222.2 |
52 |
28.4 |
1" |
11.2 |
|
46" |
1341.4 |
62 |
144.5 |
1205 |
1171.4 |
1234.9 |
1284.2 |
40 |
31.8 |
1-1/8" |
11.2 |
|
48" |
1392.2 |
65 |
149.4 |
1257.3 |
1222.2 |
1289.1 |
1335 |
44 |
31.8 |
1-1/8" |
11.2 |
|
50" |
1443 |
68.3 |
153.9 |
1308.1 |
1273 |
1339.9 |
1385.8 |
48 |
31.8 |
1-1/8" |
11.2 |
|
52" |
1493.8 |
69.9 |
157.2 |
1360.5 |
1323.8 |
1390.7 |
1436.6 |
52 |
31.8 |
1-1/8" |
11.2 |
|
54" |
1549.4 |
71.4 |
162.1 |
1412.8 |
1374.6 |
1441.5 |
1492.3 |
56 |
31.8 |
1-1/8" |
11.2 |
|
56" |
1600.2 |
73.2 |
166.6 |
1465.4 |
1425.4 |
1492.3 |
1543.1 |
60 |
31.8 |
1-1/8" |
14.2 |
|
58" |
1674.9 |
74.7 |
174.8 |
1516.2 |
1476.2 |
1543.1 |
1611.4 |
48 |
35.1 |
1-1/4" |
14.2 |
|
60" |
1725.9 |
76.2 |
179.3 |
1570 |
1527 |
1600.2 |
1662.2 |
52 |
35.1 |
1-1/4" |
14.2 |
