DIN Plate Flanges (Slip On Flanges)
DIN 2573 PN6 Flat Flange for Welding (Plate Slip On)
Standard: DIN 2573
Flange type: Flat Flange For Welding (Slip On)
Size range: DN15-DN500
Pressure: PN6, 6BAR
Material: Stainless steel , Alloy Steel , Carbon Steel
Standard: DIN 2573
Flange type: plate flange, slip on flange(flat face without neck)
Size range: DN15-DN500
Pressure class: PN6
Connection type: Flat face
Process: Forged or Stamped
Specialize: As per drawing
Material:
Stainless Steel Material:
ASTM A182 F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L
Duplex stainless steel UNS S32304,S31803,S32205.
Super Duplex stainless steel UNS S32750/S32760/S31260/S32550/S32707
Carbon Steel Material:
ASTM A105, Q235, A350 LF2,ASTM A694 F42/F46/F52/F60/F65/F70/F80
Alloy Steel Material:
ASTM A 182, GR F1,F5, F9, F11, F22, F91
Copper&Nickel Alloy Material:
CU/NI 90/10, CU/NI 70/30
Nickel Alloy Material:
Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276
Surface treatment: Anti-rust oil, transparent/yellow/black,Anti-rust paint, Zinc,Hot dipped galvanized
Usage: Oil field, Offshore, Water system, Shipbuilding, Natural gas,Electric power, Pipe projects,etc
Standard: DIN 2573
Flange type: plate flange, slip on flange(flat face without neck)
Size range: DN15-DN500
Pressure class: PN6
Connection type: Flat faceProcess: Forged or Stamped
|
DN |
ISO |
DIN |
d5 |
D |
b |
k |
No. of Holes |
d2 |
KG |
|
10 |
- |
14 |
14.5 |
75 |
12 |
50 |
4 |
11 |
0.36 |
|
|
17.2 |
- |
17.7 |
75 |
12 |
50 |
4 |
11 |
0.36 |
|
15 |
- |
20 |
21 |
80 |
12 |
55 |
4 |
11 |
0.41 |
|
|
21.3 |
- |
22 |
80 |
12 |
55 |
4 |
11 |
0.4 |
|
20 |
- |
25 |
26 |
90 |
14 |
65 |
4 |
11 |
0.6 |
|
|
26.9 |
- |
27.6 |
90 |
14 |
65 |
4 |
11 |
0.59 |
|
25 |
- |
30 |
31 |
100 |
14 |
75 |
4 |
11 |
0.74 |
|
|
33.7 |
- |
34.4 |
100 |
14 |
75 |
4 |
11 |
0.72 |
|
32 |
- |
38 |
39 |
120 |
16 |
90 |
4 |
14 |
1.19 |
|
|
42.4 |
- |
43.1 |
120 |
16 |
90 |
4 |
14 |
1.16 |
|
40 |
- |
44.5 |
45.5 |
130 |
16 |
100 |
4 |
14 |
1.39 |
|
|
48.3 |
- |
49 |
130 |
16 |
100 |
4 |
14 |
1.35 |
|
50 |
- |
57 |
58.1 |
140 |
16 |
110 |
4 |
14 |
1.52 |
|
|
60.3 |
- |
61.1 |
140 |
16 |
110 |
4 |
14 |
1.49 |
|
65 |
76.1 |
- |
77.1 |
160 |
16 |
130 |
4 |
14 |
1.86 |
|
80 |
88.9 |
- |
90.3 |
190 |
18 |
150 |
4 |
14 |
2.96 |
|
100 |
- |
108 |
109.6 |
210 |
18 |
170 |
4 |
18 |
3.42 |
|
|
114.3 |
- |
115.9 |
210 |
18 |
170 |
4 |
18 |
3.26 |
|
125 |
- |
133 |
134.8 |
240 |
20 |
200 |
8 |
18 |
4.54 |
|
|
139.7 |
- |
141.6 |
240 |
20 |
200 |
8 |
18 |
4.31 |
|
150 |
- |
159 |
161.1 |
265 |
20 |
225 |
8 |
18 |
5.34 |
|
|
168.2 |
- |
170.5 |
265 |
20 |
225 |
8 |
18 |
4.76 |
|
200 |
219.1 |
- |
221.8 |
320 |
22 |
280 |
8 |
18 |
6.87 |
|
250 |
- |
267 |
270.2 |
325 |
24 |
335 |
12 |
18 |
9.42 |
|
|
273 |
- |
276.2 |
325 |
24 |
335 |
12 |
18 |
8.94 |
|
300 |
323.9 |
- |
327.6 |
440 |
24 |
395 |
12 |
22 |
11.91 |
|
350 |
355.6 |
- |
359.7 |
480 |
26 |
445 |
12 |
22 |
16.52 |
|
|
- |
368 |
372.2 |
490 |
26 |
445 |
12 |
22 |
15.35 |
|
400 |
406.4 |
- |
411 |
540 |
28 |
495 |
16 |
22 |
18.84 |
|
|
- |
419 |
423.7 |
540 |
28 |
495 |
16 |
22 |
18.01 |
|
450 |
457 |
- |
462.3 |
595 |
30 |
550 |
16 |
22 |
24.52 |
|
500 |
508 |
- |
513.6 |
645 |
30 |
600 |
20 |
22 |
26.37 |
