UNI Plate Flange (Slip on Flange)
UNI 6084 plate flange PN40
Standard: UNI
Flange type: plate flange
Size range: DN15-DN1000
Pressure: PN40
Material: Stainless steel , Alloy Steel , Carbon Steel
Standard: UNI
Flange type: plate flange
Size range: DN15-DN1000
Pressure class: PN40
Face type: Flat Face(FF),Raised Face(RF),Ring Joint(RJT)
Specialize: As per drawing
Material:
Stainless Steel Material:
ASTM A182 F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L
Duplex stainless steel UNS S32304,S31803,S32205.
Super Duplex stainless steel UNS S32750/S32760/S31260/S32550/S32707
Carbon Steel Material:
ASTM A105, Q235, A350 LF2,ASTM A694 F42/F46/F52/F60/F65/F70/F80
Alloy Steel Material:
ASTM A 182, GR F1,F5, F9, F11, F22, F91
Copper&Nickel Alloy Material:
CU/NI 90/10, CU/NI 70/30
Nickel Alloy Material:
Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276
Surface treatment: Anti-rust oil, transparent/yellow/black,Anti-rust paint, Zinc,Hot dipped galvanized
Usage: Oil field, Offshore, Water system, Shipbuilding, Natural gas,Electric power, Pipe projects,etc.
Standard: UNI
Flange type: plate flange
Size range: DN15-DN1000
Pressure class: PN40
Material : Stainless steel , Alloy Steel , Carbon Steel
|
DN |
TUBO |
d1 |
a |
D |
b |
f |
VITI |
N.FORL |
Kg |
||
|
DIN |
ISO |
DIN |
ISO |
||||||||
|
10 |
13.5 |
17.2 |
14 |
17.5 |
60 |
90 |
14 |
14 |
M12 |
4 |
0.600 |
|
15 |
20 |
21.3 |
20,5 |
22 |
65 |
95 |
14 |
14 |
M12 |
4 |
0.670 |
|
20 |
25 |
26.9 |
25.5 |
27.5 |
75 |
105 |
16 |
14 |
M12 |
4 |
0.940 |
|
25 |
30 |
33,7 |
30.5 |
34 |
85 |
115 |
16 |
14 |
M12 |
|
1.110 |
|
32 |
38 |
42.4 |
38.5 |
43 |
100 |
140 |
18 |
18 |
M16 |
4 |
1.830 |
|
40 |
44.5 |
48.3 |
45 |
49 |
110 |
150 |
18 |
18 |
M16 |
4 |
2.090 |
|
50 |
57 |
60.3 |
58 |
61.5 |
125 |
165 |
20 |
18 |
M16 |
|
2.730 |
|
65 |
76.1 |
77 |
145 |
185 |
24 |
18 |
M16 |
6 |
3.800 |
||
|
80 |
88.9 |
90 |
160 |
200 |
26 |
18 |
M16 |
|
4,700 |
||
|
100 |
108 |
114.3 |
109 |
115.5 |
190 |
235 |
26 |
22 |
M20 |
8 |
6.090 |
|
125 |
133 |
139,7 |
134.5 |
141 |
220 |
270 |
28 |
25 |
M22 |
8 |
8.220 |
|
150 |
159 |
168.3 |
160.5 |
170 |
250 |
300 |
30 |
25 |
M22 |
8 |
10.300 |
|
200 |
219.1 |
221 |
320 |
375 |
36 |
30 |
M27 |
12 |
18.000 |
||
|
250 |
267 |
273 |
269 |
275 |
385 |
450 |
44 |
33 |
M30 |
12 |
30.900 |
|
300 |
323.9 |
326 |
450 |
515 |
48 |
33 |
M30 |
16 |
41.900 |
||
|
350 |
368 |
355.6 |
370.5 |
358 |
510 |
580 |
54 |
36 |
M33 |
16 |
62.400 |
|
400 |
419 |
406.4 |
422 |
409 |
585 |
660 |
60 |
39 |
M36x3 |
16 |
90.300 |
